VM3000 MICROPHONE MEMS DIGITAL PDM OMNI
PUI Audio, Inc. mikrofon AOM-6742P-2-R. 30 Hz ~ 15.0 kHz, Circular, Electret Condenser, -42dB ±3dB, Omnidirectional, Analog çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | VM3000 |
| Mfr | Vesper Technologies Inc. |
| Description | MICROPHONE MEMS DIGITAL PDM OMNI |
| Series | - |
| Type | MEMS (Silicon) |
| Output Type | Digital, PDM |
| Direction | Omnidirectional |
| Frequency Range | 20 Hz ~ 8.0 kHz |
| Sensitivity | -26dB ±1dB @ 94dB SPL |
| S/N Ratio | 62dB |
| Impedance | - |
| Voltage - Rated | 1.8 V |
| Voltage Range | 1.6 V ~ 3.6 V |
| Current - Supply | 775 µA |
| Port Location | Bottom |
| Ratings | IP57 - Dust Protected, Waterproof |
| Termination | Solder Pads |
| Size / Dimension | 0.138" L x 0.104" W (3.50mm x 2.65mm) |
| Height (Max) | 0.051" (1.30mm) |
| Shape | Rectangular |
