VM2020 MICROPHONE MEMS ANALOG OMNI
PUI Audio, Inc. mikrofon POM-2730L-HD-R. 20 Hz ~ 20.0 kHz, Circular, Electret Condenser, -30dB ±3dB, Omnidirectional, Analog çıkışlı.
Özellik | Değer |
---|---|
Datasheet | PDF Datasheet indir |
Mfr Part # | VM2020 |
Mfr | Vesper Technologies Inc. |
Description | MICROPHONE MEMS ANALOG OMNI |
Series | Vesper |
Type | MEMS (Silicon) |
Output Type | Analog |
Direction | Omnidirectional |
Frequency Range | 80 Hz ~ 10.0 kHz |
Sensitivity | - |
S/N Ratio | 50dB |
Impedance | - |
Voltage - Rated | 2.6 V |
Voltage Range | - |
Current - Supply | 248 µA |
Port Location | Bottom |
Ratings | IP57 - Dust Protected, Waterproof |
Termination | Solder Pads |
Size / Dimension | 0.148" L x 0.116" W (3.76mm x 2.95mm) |
Height (Max) | 0.055" (1.40mm) |
Shape | Rectangular |
