VM2020 MICROPHONE MEMS ANALOG OMNI - MIKROFON | MIC
0,00 TL
Elektromekanik Komponent | Ses Ürünleri | Mikrofon Çeşitleri
VM2020 MICROPHONE MEMS ANALOG OMNI
PUI Audio, Inc. mikrofon POM-2730L-HD-R. 20 Hz ~ 20.0 kHz, Circular, Electret Condenser, -30dB ±3dB, Omnidirectional, Analog çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | VM2020 |
| Mfr | Vesper Technologies Inc. |
| Description | MICROPHONE MEMS ANALOG OMNI |
| Series | Vesper |
| Type | MEMS (Silicon) |
| Output Type | Analog |
| Direction | Omnidirectional |
| Frequency Range | 80 Hz ~ 10.0 kHz |
| Sensitivity | - |
| S/N Ratio | 50dB |
| Impedance | - |
| Voltage - Rated | 2.6 V |
| Voltage Range | - |
| Current - Supply | 248 µA |
| Port Location | Bottom |
| Ratings | IP57 - Dust Protected, Waterproof |
| Termination | Solder Pads |
| Size / Dimension | 0.148" L x 0.116" W (3.76mm x 2.95mm) |
| Height (Max) | 0.055" (1.40mm) |
| Shape | Rectangular |
