TOM-3046L-R MICROPHONE COND ANALOG OMNI - MIKROFON | MIC
0,00 TL
Elektromekanik Komponent | Ses Ürünleri | Mikrofon Çeşitleri
TOM-3046L-R MICROPHONE COND ANALOG OMNI
Knowles mikrofon TC-32348-000. 100 Hz ~ 6.0 kHz, Rectangular, -, -40dB ±3dB @ 94dB SPL, -, Analog çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | TOM-3046L-R |
| Mfr | PUI Audio, Inc. |
| Description | MICROPHONE COND ANALOG OMNI |
| Series | TOM |
| Type | Electret Condenser |
| Output Type | Analog |
| Direction | Omnidirectional |
| Frequency Range | 30 Hz ~ 15.0 kHz |
| Sensitivity | -46dB ±3dB |
| S/N Ratio | 60dB |
| Impedance | 2.2 kOhms |
| Voltage - Rated | 2 V |
| Voltage Range | 2 V ~ 10.0 V |
| Current - Supply | 500 µA |
| Port Location | Top |
| Ratings | - |
| Termination | Solder Pads |
| Size / Dimension | 0.177" Dia (4.50mm) |
| Height (Max) | 0.126" (3.20mm) |
| Shape | Circular |
