SPM0687LR5H-1 WINFREY MIC HI SNR/AOP BOT PORT - MIKROFON | MIC
0,00 TL + KDV
Elektromekanik Komponent | Ses Ürünleri | Mikrofon Çeşitleri
SPM0687LR5H-1 WINFREY MIC HI SNR/AOP BOT PORT
TDK InvenSense mikrofon ICS-40638. 35 Hz ~ 20.0 kHz, Rectangular, MEMS (Silicon), -43dB ±1dB @ 94dB SPL, Omnidirectional, Analog çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | SPM0687LR5H-1 |
| Mfr | Knowles |
| Description | WINFREY MIC HI SNR/AOP BOT PORT |
| Series | SiSonic™ SPM |
| Type | MEMS (Silicon) |
| Output Type | Analog |
| Direction | Omnidirectional |
| Frequency Range | - |
| Sensitivity | -40dB ±1dB @ 130dB SPL |
| S/N Ratio | 70dB |
| Impedance | - |
| Voltage - Rated | - |
| Voltage Range | 2.3 V ~ 3.6 V |
| Current - Supply | 285 µA |
| Port Location | Bottom |
| Ratings | - |
| Termination | Solder Pads |
| Size / Dimension | 0.186" L x 0.148" W (4.72mm x 3.76mm) |
| Height (Max) | 0.049" (1.25mm) |
| Shape | Rectangular |
