SMO04C-38/1316 MEMS MICROPHONE - MIKROFON | MIC
0,00 TL
Elektromekanik Komponent | Ses Ürünleri | Mikrofon Çeşitleri
SMO04C-38/1316 MEMS MICROPHONE
Knowles mikrofon SPK0838HT4H-1. 100 Hz ~ 10.0 kHz, Rectangular, MEMS (Silicon), -26dB ±3dB @ 94dB SPL, Omnidirectional, Digital, PDM çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | SMO04C-38/1316 |
| Mfr | BeStar Technologies, Inc. |
| Description | MEMS MICROPHONE |
| Series | SMO |
| Type | MEMS (Silicon) |
| Output Type | Analog |
| Direction | Omnidirectional |
| Frequency Range | 100 Hz ~ 10.0 kHz |
| Sensitivity | -38dB ±1dB |
| S/N Ratio | 63dB |
| Impedance | - |
| Voltage - Rated | - |
| Voltage Range | 1.6 V ~ 3.6 V |
| Current - Supply | 0.2 mA |
| Port Location | Top |
| Ratings | - |
| Termination | Solder Pads |
| Size / Dimension | 0.148" L x 0.116" W (3.76mm x 2.95mm) |
| Height (Max) | 0.043" (1.10mm) |
| Shape | Rectangle |
