PKLCS1212E20A0-R1 AUDIO PIEZO TRANSDUCER 12.5V SMD - ALARM, BUZZER, SIREN
0,00 TL
Elektromekanik Komponent | Ses Ürünleri | Alarm, Buzzer ve Siren Çeşitleri
PKLCS1212E20A0-R1 AUDIO PIEZO TRANSDUCER 12.5V SMD
Özellik | Değer |
---|---|
Datasheet | PDF Datasheet indir |
Mfr Part # | PKLCS1212E20A0-R1 |
Mfr | Murata Electronics |
Description | AUDIO PIEZO TRANSDUCER 12.5V SMD |
Series | PK |
Driver Circuitry | Transducer, Externally Driven |
Input Type | Zero-Peak Signal |
Voltage - Rated | 1.5 V |
Voltage Range | 12.5V (Max) |
Frequency | 2kHz |
Technology | Piezo |
Operating Mode | Single Tone |
Duration | - |
Sound Pressure Level (SPL) | 70dB @ 1.5V, 10cm |
Current - Supply | - |
Port Location | Side |
Operating Temperature | -40°C ~ 85°C |
Approval Agency | - |
Ratings | - |
Ingress Protection | - |
Mounting Type | Surface Mount |
Termination | Solder Pads |
Size / Dimension | 0.472" L x 0.472" W (12.00mm x 12.00mm) |
Height - Seated (Max) | 0.118" (3.00mm) |
