MU064602-2 MIC COND ANALOG UNI -46DB 6MM D
Knowles mikrofon SPK2611HM7H. -, Square, MEMS (Silicon), -, Omnidirectional, Digital, PDM çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | MU064602-2 |
| Mfr | DB Unlimited |
| Description | MIC COND ANALOG UNI -46DB 6MM D |
| Series | - |
| Type | Electret Condenser |
| Output Type | Analog |
| Direction | Unidirectional |
| Frequency Range | 100 Hz ~ 10.0 kHz |
| Sensitivity | -46dB ±4dB |
| S/N Ratio | 55dB |
| Impedance | - |
| Voltage - Rated | 2 V |
| Voltage Range | - |
| Current - Supply | 500 µA |
| Port Location | Top |
| Ratings | - |
| Termination | Solder Pads |
| Size / Dimension | 0.236" Dia (6.00mm) |
| Height (Max) | 0.146" (3.70mm) |
| Shape | Circular |
