MO064202-2 MIC COND ANALOG OMNI -42DB 6MM D - MIKROFON | MIC
0,00 TL
Elektromekanik Komponent | Ses Ürünleri | Mikrofon Çeşitleri
MO064202-2 MIC COND ANALOG OMNI -42DB 6MM D
Knowles mikrofon EK-23027-C36. 100 Hz ~ 10.0 kHz, Rectangular, Electret Condenser, -53dB ±2dB @ 74dB SPL, Omnidirectional, Analog çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | MO064202-2 |
| Mfr | DB Unlimited |
| Description | MIC COND ANALOG OMNI -42DB 6MM D |
| Series | - |
| Type | Electret Condenser |
| Output Type | Analog |
| Direction | Omnidirectional |
| Frequency Range | 50 Hz ~ 16.0 kHz |
| Sensitivity | -42dB |
| S/N Ratio | 60dB |
| Impedance | - |
| Voltage - Rated | 2 V |
| Voltage Range | - |
| Current - Supply | 500 µA |
| Port Location | Top |
| Ratings | - |
| Termination | Solder Pads |
| Size / Dimension | 0.236" Dia (6.00mm) |
| Height (Max) | 0.114" (2.90mm) |
| Shape | Circular |
