MN095401-1 MIC COND ANALOG NC 9.7MM D - MIKROFON | MIC
0,00 TL
Elektromekanik Komponent | Ses Ürünleri | Mikrofon Çeşitleri
MN095401-1 MIC COND ANALOG NC 9.7MM D
Gettop Acoustics mikrofon MA-FFA421-A10-4. 100 Hz ~ 10.0 kHz, Rectangular, MEMS (Silicon), -42dB ±1dB @ 94dB SPL, Omnidirectional, Analog çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | MN095401-1 |
| Mfr | DB Unlimited |
| Description | MIC COND ANALOG NC 9.7MM D |
| Series | - |
| Type | Electret Condenser |
| Output Type | Analog |
| Direction | Noise Cancelling |
| Frequency Range | 100 Hz ~ 10.0 kHz |
| Sensitivity | - |
| S/N Ratio | 55dB |
| Impedance | - |
| Voltage - Rated | 1.5 V |
| Voltage Range | - |
| Current - Supply | 500 µA |
| Port Location | Top |
| Ratings | - |
| Termination | Solder Pads |
| Size / Dimension | 0.382" Dia (9.70mm) |
| Height (Max) | 0.213" (5.40mm) |
| Shape | Circular |
