MMICT4076-00-908 MICROPHONE MEMS ANALOG -38DB - MIKROFON | MIC
0,00 TL
Elektromekanik Komponent | Ses Ürünleri | Mikrofon Çeşitleri
MMICT4076-00-908 MICROPHONE MEMS ANALOG -38DB
TDK InvenSense mikrofon MMICT4078-00-908. 80 Hz ~ 20.0 kHz, Rectangular, MEMS (Silicon), -38db ±1dB @ 136dB, -, Analog çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | MMICT4076-00-908 |
| Mfr | TDK InvenSense |
| Description | MICROPHONE MEMS ANALOG -38DB |
| Series | MMIC |
| Type | MEMS (Silicon) |
| Output Type | Analog |
| Direction | - |
| Frequency Range | 80 Hz ~ 20.0 kHz |
| Sensitivity | -38db ±1dB @ 127dB |
| S/N Ratio | 63dB |
| Impedance | - |
| Voltage - Rated | - |
| Voltage Range | 1.6 V ~ 3.6 V |
| Current - Supply | - |
| Port Location | Bottom |
| Ratings | - |
| Termination | Solder Pads |
| Size / Dimension | 0.108" L x 0.073" W (2.75mm x 1.85mm) |
| Height (Max) | 0.035" (0.90mm) |
| Shape | Rectangular |
