Elektromekanik Komponent | Ses Ürünleri | Mikrofon Çeşitleri

MM034202-11 MICROPHONE MEMS ANALOG OMNI

DB Unlimited mikrofon MM033802-6. 100 Hz ~ 10.0 kHz, Rectangular, MEMS (Silicon), -38db ±1dB, Omnidirectional, Analog çıkışlı.

Özellik	Değer
Datasheet	PDF Datasheet indir
Mfr Part #	MM034202-11
Mfr	DB Unlimited
Description	MICROPHONE MEMS ANALOG OMNI
Series	-
Type	MEMS (Silicon)
Output Type	Analog
Direction	Omnidirectional
Frequency Range	100 Hz ~ 10.0 kHz
Sensitivity	-42dB ±1dB
S/N Ratio	59dB
Impedance	-
Voltage - Rated	2 V
Voltage Range	-
Current - Supply	190 µA
Port Location	Top
Ratings	-
Termination	Solder Pads
Size / Dimension	0.148" L x 0.088" W (3.76mm x 2.24mm)
Height (Max)	0.047" (1.20mm)
Shape	Rectangular
