MM033802-6 MICROPHONE MEMS ANALOG OMNI - MIKROFON | MIC
0,00 TL
omponent | Ses Ürünleri | Mikrofon Çeşitleri
MM033802-6 MICROPHONE MEMS ANALOG OMNI
Vesper Technologies Inc. mikrofon VM1010. 100 Hz ~ 10.0 kHz, Rectangular, Piezo MEMS, -38dB ±3dB @ 94dB SPL, Omnidirectional, Analog çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | MM033802-6 |
| Mfr | DB Unlimited |
| Description | MICROPHONE MEMS ANALOG OMNI |
| Series | - |
| Type | MEMS (Silicon) |
| Output Type | Analog |
| Direction | Omnidirectional |
| Frequency Range | 100 Hz ~ 10.0 kHz |
| Sensitivity | -38db ±1dB |
| S/N Ratio | 65dB |
| Impedance | - |
| Voltage - Rated | 2 V |
| Voltage Range | - |
| Current - Supply | 100 µA |
| Port Location | Bottom |
| Ratings | - |
| Termination | Solder Pads |
| Size / Dimension | 0.138" L x 0.104" W (3.50mm x 2.65mm) |
| Height (Max) | 0.043" (1.08mm) |
| Shape | Rectangular |
