MM023802-2 MICROPHONE MEMS ANALOG OMNI
CUI Devices mikrofon CMM-4030D-261-I2S-TR. 100 Hz ~ 10.0 kHz, Rectangular, MEMS (Silicon), -26dB ±1dB, Omnidirectional, Digital, I²S çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | MM023802-2 |
| Mfr | DB Unlimited |
| Description | MICROPHONE MEMS ANALOG OMNI |
| Series | - |
| Type | MEMS (Silicon) |
| Output Type | Analog |
| Direction | Omnidirectional |
| Frequency Range | 100 Hz ~ 10.0 kHz |
| Sensitivity | -38dB ±3dB |
| S/N Ratio | 61dB |
| Impedance | - |
| Voltage - Rated | 2 V |
| Voltage Range | - |
| Current - Supply | 180 µA |
| Port Location | Bottom |
| Ratings | - |
| Termination | Solder Pads |
| Size / Dimension | 0.108" L x 0.073" W (2.75mm x 1.85mm) |
| Height (Max) | 0.041" (1.05mm) |
| Shape | Rectangular |
