MEO-627PN-02-643 REV.1 ELECTRET CONDENSER MICROPHONE - MIKROFON | MIC
0,00 TL + KDV
Elektromekanik Komponent | Ses Ürünleri | Mikrofon Çeşitleri
MEO-627PN-02-643 REV.1 ELECTRET CONDENSER MICROPHONE
DB Unlimited mikrofon MO044002-1. 100 Hz ~ 16.0 kHz, Circular, Electret Condenser, -40dB, Omnidirectional, Analog çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | MEO-627PN-02-643 REV.1 |
| Mfr | Intervox |
| Description | ELECTRET CONDENSER MICROPHONE |
| Series | MEO-627-02 |
| Type | Electret Condenser |
| Output Type | Analog |
| Direction | Omnidirectional |
| Frequency Range | 20 Hz ~ 16.0 kHz |
| Sensitivity | -64dB ±3dB |
| S/N Ratio | 36dB |
| Impedance | 2.2 kOhms |
| Voltage - Rated | 2 V |
| Voltage Range | - |
| Current - Supply | 500 µA |
| Port Location | Top |
| Ratings | - |
| Termination | PC Pins |
| Size / Dimension | 0.236" Dia (6.00mm) |
| Height (Max) | 0.106" (2.70mm) |
| Shape | Circular |
