Elektromekanik Komponent | Ses Ürünleri | Mikrofon Çeşitleri
MA-FRA381-A13-4 BP ANALOG MEMS MIC 2.75X1.85
Gettop Acoustics mikrofon MD-HRA261-H10-2. 100 Hz ~ 10.0 kHz, Rectangular, MEMS (Silicon), -26dB ±1dB @ 94dB SPL, Omnidirectional, Digital, PDM çıkışlı.
Özellik | Değer |
---|---|
Datasheet | PDF Datasheet indir |
Mfr Part # | MA-FRA381-A13-4 |
Mfr | Gettop Acoustics |
Description | BP ANALOG MEMS MIC 2.75X1.85 |
Series | - |
Type | MEMS (Silicon) |
Output Type | Analog |
Direction | Omnidirectional |
Frequency Range | 100 Hz ~ 10.0 kHz |
Sensitivity | -38dB ±1dB @ 94dB SPL |
S/N Ratio | 63dB |
Impedance | 400 Ohms |
Voltage - Rated | 2 V |
Voltage Range | 1.6 V ~ 3.6 V |
Current - Supply | 200 µA |
Port Location | Bottom |
Ratings | - |
Termination | Solder Pads |
Size / Dimension | 0.108" L x 0.073" W (2.75mm x 1.85mm) |
Height (Max) | 0.039" (1.00mm) |
Shape | Rectangular |
