IE320425-1 ELECTRO-MECHANICAL INDICATOR - ALARM, BUZZER, SIREN
0,00 TL
Elektromekanik Komponent | Ses Ürünleri | Alarm, Buzzer ve Siren Çeşitleri
IE320425-1 ELECTRO-MECHANICAL INDICATOR
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | IE320425-1 |
| Mfr | DB Unlimited |
| Description | ELECTRO-MECHANICAL INDICATOR |
| Series | - |
| Driver Circuitry | Indicator, Internally Driven |
| Input Type | DC |
| Voltage - Rated | 24 V |
| Voltage Range | 15 ~ 27V |
| Frequency | 400Hz |
| Technology | Electromechanical |
| Operating Mode | Single Tone |
| Duration | - |
| Sound Pressure Level (SPL) | - |
| Current - Supply | 30mA |
| Port Location | Top |
| Operating Temperature | -10°C ~ 60°C |
| Approval Agency | - |
| Ratings | - |
| Ingress Protection | - |
| Mounting Type | Panel Mount, Flange |
| Termination | Wire Leads |
| Size / Dimension | 1.260" L x 0.669" W (32.00mm x 17.00mm) |
| Height - Seated (Max) | 0.610" (15.50mm) |
