IE122412-2 ELECTRO-MECHANICAL INDICATOR - ALARM, BUZZER, SIREN
0,00 TL
Elektromekanik Komponent | Ses Ürünleri | Alarm, Buzzer ve Siren Çeşitleri
IE122412-2 ELECTRO-MECHANICAL INDICATOR
Özellik | Değer |
---|---|
Datasheet | PDF Datasheet indir |
Mfr Part # | IE122412-2 |
Mfr | DB Unlimited |
Description | ELECTRO-MECHANICAL INDICATOR |
Series | - |
Driver Circuitry | Indicator, Internally Driven |
Input Type | DC |
Voltage - Rated | 12 V |
Voltage Range | 8 ~ 15V |
Frequency | 2.4kHz |
Technology | Electromechanical |
Operating Mode | Single Tone |
Duration | - |
Sound Pressure Level (SPL) | 85dB @ 12V, 10cm |
Current - Supply | 30mA |
Port Location | Top |
Operating Temperature | -30°C ~ 70°C |
Approval Agency | - |
Ratings | Washable |
Ingress Protection | - |
Mounting Type | Surface Mount |
Termination | Solder Pads |
Size / Dimension | 0.504" L x 0.504" W (12.80mm x 12.80mm) |
Height - Seated (Max) | 0.256" (6.50mm) |
