Elektromekanik Komponent | Ses Ürünleri | Mikrofon Çeşitleri
ICS-41351 MICROPHONE MEMS DIGITAL PDM OMNI
Knowles mikrofon SPM0687LR5H-1. -, Rectangular, MEMS (Silicon), -40dB ±1dB @ 130dB SPL, Omnidirectional, Analog çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | ICS-41351 |
| Mfr | TDK InvenSense |
| Description | MICROPHONE MEMS DIGITAL PDM OMNI |
| Series | - |
| Type | MEMS (Silicon) |
| Output Type | Digital, PDM |
| Direction | Omnidirectional |
| Frequency Range | 50 Hz ~ 20.0 kHz |
| Sensitivity | -26dB ±1dB @ 94dB SPL |
| S/N Ratio | 65dB |
| Impedance | - |
| Voltage - Rated | 1.8 V |
| Voltage Range | - |
| Current - Supply | 600 µA |
| Port Location | Top |
| Ratings | - |
| Termination | Solder Pads |
| Size / Dimension | 0.138" L x 0.104" W (3.50mm x 2.65mm) |
| Height (Max) | 0.043" (1.08mm) |
| Shape | Rectangular |
Bu ürüne ilk yorumu siz yapın!
