ICS-40619 MICROPHONE MEMS ANALOG OMNI - MIKROFON | MIC
0,00 TL
Elektromekanik Komponent | Ses Ürünleri | Mikrofon Çeşitleri
ICS-40619 MICROPHONE MEMS ANALOG OMNI
PUI Audio, Inc. mikrofon DMM-4326-T-R. 20 Hz ~ 18.0 kHz, Rectangular, MEMS (Silicon), -26dB ±1dB, Omnidirectional, Digital, PDM çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | ICS-40619 |
| Mfr | TDK InvenSense |
| Description | MICROPHONE MEMS ANALOG OMNI |
| Series | - |
| Type | MEMS (Silicon) |
| Output Type | Analog |
| Direction | Omnidirectional |
| Frequency Range | 50 Hz ~ 20.0 kHz |
| Sensitivity | -38db ±1dB |
| S/N Ratio | 67dB |
| Impedance | - |
| Voltage - Rated | - |
| Voltage Range | 1.52 V ~ 3.63 V |
| Current - Supply | 190 µA |
| Port Location | Top |
| Ratings | - |
| Termination | Solder Pads |
| Size / Dimension | 0.138" L x 0.104" W (3.50mm x 2.65mm) |
| Height (Max) | 0.043" (1.10mm) |
| Shape | Rectangular |
