ICS-40181 MICROPHONE MEMS ANALOG OMNI - MIKROFON | MIC
0,00 TL
Elektromekanik Komponent | Ses Ürünleri | Mikrofon Çeşitleri
ICS-40181 MICROPHONE MEMS ANALOG OMNI
CUI Devices mikrofon CMA-6542PF. 20 Hz ~ 20.0 kHz, Circular, Electret Condenser, -42dB ±3dB @ 94dB SPL, Omnidirectional, Analog çıkışlı.
Özellik | Değer |
---|---|
Datasheet | PDF Datasheet indir |
Mfr Part # | ICS-40181 |
Mfr | TDK InvenSense |
Description | MICROPHONE MEMS ANALOG OMNI |
Series | - |
Type | MEMS (Silicon) |
Output Type | Analog |
Direction | Omnidirectional |
Frequency Range | 60 Hz ~ 20.0 kHz |
Sensitivity | -38db ±1dB |
S/N Ratio | 65dB |
Impedance | 350 Ohms |
Voltage - Rated | - |
Voltage Range | 1.5 V ~ 3.63 V |
Current - Supply | 250 µA |
Port Location | Top |
Ratings | - |
Termination | Solder Pads |
Size / Dimension | 0.138" L x 0.104" W (3.50mm x 2.65mm) |
Height (Max) | 0.043" (1.10mm) |
Shape | Rectangular |
