HBO0302C-58/1248 BACK ELECTRET CONDENSER MICROPHO - MIKROFON | MIC
0,00 TL
Elektromekanik Komponent | Ses Ürünleri | Mikrofon Çeşitleri
HBO0302C-58/1248 BACK ELECTRET CONDENSER MICROPHO
Knowles mikrofon FG-23629-P16. 100 Hz ~ 10.0 kHz, Circular, Electret Condenser, -53dB ±3dB @ 74dB SPL, Omnidirectional, Analog çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | HBO0302C-58/1248 |
| Mfr | BeStar Technologies, Inc. |
| Description | BACK ELECTRET CONDENSER MICROPHO |
| Series | HBO |
| Type | Electret Condenser |
| Output Type | Analog |
| Direction | Omnidirectional |
| Frequency Range | 20 Hz ~ 20.0 kHz |
| Sensitivity | -38dB ±3dB |
| S/N Ratio | 65dB |
| Impedance | - |
| Voltage - Rated | 2 V |
| Voltage Range | 1 V ~ 10.0 V |
| Current - Supply | 0.5 mA |
| Port Location | Top |
| Ratings | - |
| Termination | Wire Leads |
| Size / Dimension | 0.118" Dia (3.00mm) |
| Height (Max) | 0.059" (1.50mm) |
| Shape | Circular |
