FG-23329-P07 MICROPHONE COND ANALOG OMNI - MIKROFON | MIC
0,00 TL + KDV
Elektromekanik Komponent | Ses Ürünleri | Mikrofon Çeşitleri
FG-23329-P07 MICROPHONE COND ANALOG OMNI
TDK InvenSense mikrofon MMICT390200012. -, Rectangular, MEMS (Silicon), -32dB ±1dB @ 94dB SPL, Omnidirectional, Digital, PDM çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | FG-23329-P07 |
| Mfr | Knowles |
| Description | MICROPHONE COND ANALOG OMNI |
| Series | FG |
| Type | Electret Condenser |
| Output Type | Analog |
| Direction | Omnidirectional |
| Frequency Range | 100 Hz ~ 10.0 kHz |
| Sensitivity | -53dB ±3dB @ 74dB SPL |
| S/N Ratio | - |
| Impedance | 4.4 kOhms |
| Voltage - Rated | 1.3 V |
| Voltage Range | 1.3 V ~ 3.0 V |
| Current - Supply | 50 µA |
| Port Location | Top |
| Ratings | - |
| Termination | Wire Leads |
| Size / Dimension | 0.101" Dia (2.57mm) |
| Height (Max) | 0.101" (2.57mm) |
| Shape | Circular |
