EM-9745UN MIC COND ANALOG NC -42DB 9.7MM D - MIKROFON | MIC
0,00 TL
Elektromekanik Komponent | Ses Ürünleri | Mikrofon Çeşitleri
EM-9745UN MIC COND ANALOG NC -42DB 9.7MM D
Knowles mikrofon TO-24611-000. 100 Hz ~ 5.8 kHz, Square, Electret Condenser, -56dB ±3dB @ 74dB SPL, Omnidirectional, Analog çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | EM-9745UN |
| Mfr | Soberton Inc. |
| Description | MIC COND ANALOG NC -42DB 9.7MM D |
| Series | EM |
| Type | Electret Condenser |
| Output Type | Analog |
| Direction | Noise Cancelling |
| Frequency Range | 200 Hz ~ 10.0 kHz |
| Sensitivity | -42dB ±3dB @ 94dB SPL |
| S/N Ratio | 58dB |
| Impedance | - |
| Voltage - Rated | - |
| Voltage Range | - |
| Current - Supply | 500 µA |
| Port Location | Top |
| Ratings | IP50 - Dust Protection |
| Termination | Solder Pads |
| Size / Dimension | 0.382" Dia (9.70mm) |
| Height (Max) | 0.177" (4.50mm) |
| Shape | Circular |
