CSS-H5B43-SMT-TR AUDIO MAGNETIC XDCR 4-6V SMD - ALARM, BUZZER, SIREN
0,00 TL
Elektromekanik Komponent | Ses Ürünleri | Alarm, Buzzer ve Siren Çeşitleri
CSS-H5B43-SMT-TR AUDIO MAGNETIC XDCR 4-6V SMD
Özellik | Değer |
---|---|
Datasheet | PDF Datasheet indir |
Mfr Part # | CSS-H5B43-SMT-TR |
Mfr | CUI Devices |
Description | AUDIO MAGNETIC XDCR 4-6V SMD |
Series | CSS |
Driver Circuitry | Transducer, Externally Driven |
Input Type | Zero-Peak Signal |
Voltage - Rated | 5 V |
Voltage Range | 4 ~ 6V |
Frequency | 2.73kHz |
Technology | Magnetic |
Operating Mode | Single Tone |
Duration | - |
Sound Pressure Level (SPL) | 91dB @ 5V, 10cm |
Current - Supply | 60mA |
Port Location | Top |
Operating Temperature | -30°C ~ 85°C |
Approval Agency | - |
Ratings | - |
Ingress Protection | - |
Mounting Type | Surface Mount |
Termination | Solder Pads |
Size / Dimension | 0.551" L x 0.433" W (14.00mm x 11.00mm) |
Height - Seated (Max) | 0.138" (3.50mm) |
