CPS-5952-100PM SIREN, 40 MM, 59 MM DEEP, 24VDC, - ALARM, BUZZER, SIREN
0,00 TL
Elektromekanik Komponent | Ses Ürünleri | Alarm, Buzzer ve Siren Çeşitleri
CPS-5952-100PM SIREN, 40 MM, 59 MM DEEP, 24VDC,
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | CPS-5952-100PM |
| Mfr | CUI Devices |
| Description | SIREN, 40 MM, 59 MM DEEP, 24VDC, |
| Series | CPS |
| Driver Circuitry | Indicator, Internally Driven |
| Input Type | DC |
| Voltage - Rated | 24 V |
| Voltage Range | 12 ~ 25V |
| Frequency | 3.5kHz |
| Technology | Piezo |
| Operating Mode | Warble |
| Duration | - |
| Sound Pressure Level (SPL) | 95dB @ 24V, 100cm |
| Current - Supply | 100mA |
| Port Location | User Defined |
| Operating Temperature | -20°C ~ 70°C |
| Approval Agency | - |
| Ratings | - |
| Ingress Protection | - |
| Mounting Type | Bracket Mount |
| Termination | Wire Leads |
| Size / Dimension | 1.772" L x 1.575" W (45.00mm x 40.00mm) |
| Height - Seated (Max) | 2.335" (59.30mm) |
