CPS-4013-110T BUZZER, 40 MM ROUND, 13 MM DEEP, - ALARM, BUZZER, SIREN
0,00 TL + KDV
Elektromekanik Komponent | Ses Ürünleri | Alarm, Buzzer ve Siren Çeşitleri
CPS-4013-110T BUZZER, 40 MM ROUND, 13 MM DEEP,
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | CPS-4013-110T |
| Mfr | CUI Devices |
| Description | BUZZER, 40 MM ROUND, 13 MM DEEP, |
| Series | CPS |
| Driver Circuitry | Transducer, Externally Driven |
| Input Type | DC |
| Voltage - Rated | 9 V |
| Voltage Range | 6 ~ 12V |
| Frequency | 3.2kHz |
| Technology | Piezo |
| Operating Mode | Single Tone |
| Duration | - |
| Sound Pressure Level (SPL) | 110dB @ 9V, 30cm |
| Current - Supply | 50mA |
| Port Location | Top |
| Operating Temperature | -20°C ~ 60°C |
| Approval Agency | - |
| Ratings | - |
| Ingress Protection | - |
| Mounting Type | Through Hole |
| Termination | PC Pins |
| Size / Dimension | 1.575" Dia (40.00mm) |
| Height - Seated (Max) | 0.516" (13.10mm) |
