CPI-42533C-120 AUDIO PIEZO INDICATOR 6-28V - ALARM, BUZZER, SIREN
0,00 TL
Elektromekanik Komponent | Ses Ürünleri | Alarm, Buzzer ve Siren Çeşitleri
CPI-42533C-120 AUDIO PIEZO INDICATOR 6-28V
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | CPI-42533C-120 |
| Mfr | CUI Devices |
| Description | AUDIO PIEZO INDICATOR 6-28V |
| Series | CPI |
| Driver Circuitry | Indicator, Internally Driven |
| Input Type | DC |
| Voltage - Rated | 12 V |
| Voltage Range | 6 ~ 28V |
| Frequency | 2.8kHz |
| Technology | Piezo |
| Operating Mode | Pin Selectable |
| Duration | - |
| Sound Pressure Level (SPL) | 87dB @ 12V, 30cm |
| Current - Supply | 11mA, 13mA |
| Port Location | Top |
| Operating Temperature | -30°C ~ 85°C |
| Approval Agency | - |
| Ratings | - |
| Ingress Protection | - |
| Mounting Type | Panel Mount |
| Termination | Wire Leads |
| Size / Dimension | 1.673" Dia (42.50mm) |
| Height - Seated (Max) | 1.319" (33.50mm) |
