CPE-750PA AUDIO PIEZO IND 0.7-15V PNL MNT - ALARM, BUZZER, SIREN
0,00 TL + KDV
Elektromekanik Komponent | Ses Ürünleri | Alarm, Buzzer ve Siren Çeşitleri
CPE-750PA AUDIO PIEZO IND 0.7-15V PNL MNT
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | CPE-750PA |
| Mfr | CUI Devices |
| Description | AUDIO PIEZO IND 0.7-15V PNL MNT |
| Series | CPE |
| Driver Circuitry | Indicator, Internally Driven |
| Input Type | DC |
| Voltage - Rated | 12 V |
| Voltage Range | 0.7 ~ 15V |
| Frequency | 3.6kHz |
| Technology | Piezo |
| Operating Mode | Single Tone |
| Duration | - |
| Sound Pressure Level (SPL) | 98dB @ 12V, 30cm |
| Current - Supply | 20mA |
| Port Location | Top |
| Operating Temperature | -30°C ~ 80°C |
| Approval Agency | - |
| Ratings | - |
| Ingress Protection | - |
| Mounting Type | Panel Mount |
| Termination | PC Pins |
| Size / Dimension | 1.488" Dia (37.80mm) |
| Height - Seated (Max) | 0.945" (24.00mm) |
