CPE-171 AUDIO PIEZO TRANSDUCER 30V TH - ALARM, BUZZER, SIREN
0,00 TL
Elektromekanik Komponent | Ses Ürünleri | Alarm, Buzzer ve Siren Çeşitleri
CPE-171 AUDIO PIEZO TRANSDUCER 30V TH
Özellik | Değer |
---|---|
Datasheet | PDF Datasheet indir |
Mfr Part # | CPE-171 |
Mfr | CUI Devices |
Description | AUDIO PIEZO TRANSDUCER 30V TH |
Series | CPE |
Driver Circuitry | Transducer, Externally Driven |
Input Type | Peak-Peak Signal |
Voltage - Rated | 10 V |
Voltage Range | 30V (Max) |
Frequency | - |
Technology | Piezo |
Operating Mode | Single Tone |
Duration | - |
Sound Pressure Level (SPL) | 75dB @ 10V, 10cm |
Current - Supply | 4mA |
Port Location | Top |
Operating Temperature | -30°C ~ 85°C |
Approval Agency | - |
Ratings | Washable |
Ingress Protection | - |
Mounting Type | Through Hole |
Termination | PC Pins |
Size / Dimension | 0.354" Dia (9.00mm) |
Height - Seated (Max) | 0.335" (8.50mm) |
