CMP-5247TF-K MIC COND ANALOG NC -47DB 9.7MM D
Knowles mikrofon EM-23046-C36. 100 Hz ~ 5.0 kHz, Square, Electret Condenser, -56dB ±3dB @ 74dB SPL, Omnidirectional, Analog çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | CMP-5247TF-K |
| Mfr | CUI Devices |
| Description | MIC COND ANALOG NC -47DB 9.7MM D |
| Series | - |
| Type | Electret Condenser |
| Output Type | Analog |
| Direction | Noise Cancelling |
| Frequency Range | 100 Hz ~ 20.0 kHz |
| Sensitivity | -47dB ±3dB @ 94dB SPL |
| S/N Ratio | 58dB |
| Impedance | 2.2 kOhms |
| Voltage - Rated | - |
| Voltage Range | 1.5 V ~ 10.0 V |
| Current - Supply | 500 µA |
| Port Location | Top |
| Ratings | - |
| Termination | Solder Pads |
| Size / Dimension | 0.382" Dia (9.70mm) |
| Height (Max) | 0.213" (5.40mm) |
| Shape | Circular |
