CMM-4030DT-26354-TR MICROPHONE MEMS DIGITAL PDM OMNI
DB Unlimited mikrofon MM042602-13. 100 Hz ~ 10.0 kHz, Rectangular, MEMS (Silicon), -26dB ±1dB, Omnidirectional, Digital çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | CMM-4030DT-26354-TR |
| Mfr | CUI Devices |
| Description | MICROPHONE MEMS DIGITAL PDM OMNI |
| Series | CMM |
| Type | MEMS (Silicon) |
| Output Type | Digital, PDM |
| Direction | Omnidirectional |
| Frequency Range | 100 Hz ~ 10.0 kHz |
| Sensitivity | - |
| S/N Ratio | 65dB |
| Impedance | - |
| Voltage - Rated | 2 V |
| Voltage Range | - |
| Current - Supply | 540 µA |
| Port Location | Top |
| Ratings | - |
| Termination | Solder Pads |
| Size / Dimension | 0.157" L x 0.118" W (4.00mm x 3.00mm) |
| Height (Max) | 0.043" (1.10mm) |
| Shape | Rectangular |
