CMM-3526D-261-I2S-TR MICROPHONE, 3.5MM X 2.65MM X 0.9
DB Unlimited mikrofon MM042602-15. 100 Hz ~ 10.0 kHz, Rectangular, MEMS (Silicon), -26dB ±1dB, Omnidirectional, Digital çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | CMM-3526D-261-I2S-TR |
| Mfr | CUI Devices |
| Description | MICROPHONE, 3.5MM X 2.65MM X 0.9 |
| Series | CMM |
| Type | MEMS (Silicon) |
| Output Type | Digital, I²S |
| Direction | Omnidirectional |
| Frequency Range | 100 Hz ~ 10.0 kHz |
| Sensitivity | -26dB ±1dB |
| S/N Ratio | 64dB |
| Impedance | - |
| Voltage - Rated | 1.8 V |
| Voltage Range | 1.6 V ~ 3.6 V |
| Current - Supply | 1 mA |
| Port Location | Bottom |
| Ratings | - |
| Termination | Solder Pads |
| Size / Dimension | 0.138" L x 0.104" W (3.50mm x 2.65mm) |
| Height (Max) | 0.043" (1.08mm) |
| Shape | Rectangular |
