BCM4013OLFC-42-JST-ZHR-2 ELECTRO MAGNET DYNAMIC SPEAKER - MIKROFON | MIC
0,00 TL
Elektromekanik Komponent | Ses Ürünleri | Mikrofon Çeşitleri
BCM4013OLFC-42-JST-ZHR-2 ELECTRO MAGNET DYNAMIC SPEAKER
Knowles mikrofon FG-23652-D65. 100 Hz ~ 10.0 kHz, Circular, Electret Condenser, -53dB ±3dB @ 74dB SPL, Omnidirectional, Analog çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | BCM4013OLFC-42-JST-ZHR-2 |
| Mfr | BeStar Technologies, Inc. |
| Description | ELECTRO MAGNET DYNAMIC SPEAKER |
| Series | BCM |
| Type | Electret Condenser |
| Output Type | Analog |
| Direction | Omnidirectional |
| Frequency Range | 50 Hz ~ 16.0 kHz |
| Sensitivity | -42dB ±3dB |
| S/N Ratio | 58dB |
| Impedance | - |
| Voltage - Rated | 2 V |
| Voltage Range | 1 V ~ 10.0 V |
| Current - Supply | 0.5 mA |
| Port Location | Top |
| Ratings | - |
| Termination | Wire Leads with Connector |
| Size / Dimension | 0.157" Dia (4.00mm) |
| Height (Max) | 0.051" (1.30mm) |
| Shape | Circular |
