AST605Q AUDIO MAGNETIC XDCR 4-7V SMD - ALARM, BUZZER, SIREN
0,00 TL
Elektromekanik Komponent | Ses Ürünleri | Alarm, Buzzer ve Siren Çeşitleri
AST605Q AUDIO MAGNETIC XDCR 4-7V SMD
Özellik | Değer |
---|---|
Datasheet | PDF Datasheet indir |
Mfr Part # | AST605Q |
Mfr | Mallory Sonalert Products Inc. |
Description | AUDIO MAGNETIC XDCR 4-7V SMD |
Series | AST |
Driver Circuitry | Transducer, Externally Driven |
Input Type | Peak-Peak Signal |
Voltage - Rated | 5 V |
Voltage Range | 4 ~ 7V |
Frequency | 2.4kHz |
Technology | Magnetic |
Operating Mode | Single Tone |
Duration | - |
Sound Pressure Level (SPL) | 87dB @ 5V, 10cm |
Current - Supply | 50mA |
Port Location | Top |
Operating Temperature | -40°C ~ 85°C |
Approval Agency | - |
Ratings | Washable |
Ingress Protection | - |
Mounting Type | Surface Mount |
Termination | Solder Pads |
Size / Dimension | 0.496" L x 0.496" W (12.60mm x 12.60mm) |
Height - Seated (Max) | 0.283" (7.20mm) |
