AST0927MW-3.6TRQ SMT TRANSDUCER,2-5VAC,85DB,2730H - ALARM, BUZZER, SIREN
0,00 TL
Elektromekanik Komponent | Ses Ürünleri | Alarm, Buzzer ve Siren Çeşitleri
AST0927MW-3.6TRQ SMT TRANSDUCER,2-5VAC,85DB,2730H
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | AST0927MW-3.6TRQ |
| Mfr | Mallory Sonalert Products Inc. |
| Description | SMT TRANSDUCER,2-5VAC,85DB,2730H |
| Series | AST |
| Driver Circuitry | Transducer, Externally Driven |
| Input Type | Peak-Peak Signal |
| Voltage - Rated | 3.6 V |
| Voltage Range | 2 ~ 5V |
| Frequency | 2.73kHz |
| Technology | Magnetic |
| Operating Mode | Single Tone |
| Duration | - |
| Sound Pressure Level (SPL) | 85dB @ 3.6V, 10cm |
| Current - Supply | 90mA |
| Port Location | Side |
| Operating Temperature | -30°C ~ 70°C |
| Approval Agency | - |
| Ratings | - |
| Ingress Protection | - |
| Mounting Type | Surface Mount |
| Termination | Solder Pads |
| Size / Dimension | 0.354" Dia (9.00mm) |
| Height - Seated (Max) | 0.126" (3.20mm) |
